Skid Steer Loader HT1000

Compact and Agile: Its small footprint and nimble maneuverability enable it to operate in areas inaccessible to larger equipment, significantly expanding its operational reach.

Multi-Functional: By quickly swapping out different attachments, it can swiftly switch between work modes to perform multiple functions, reducing equipment procurement costs and enhancing utilization rates.

Easy to Operate: Operators can master its controls after minimal training, lowering labor and training expenses.


Product Details

Skid steer loaders, also known as skid steer loaders or multi-purpose utility vehicles, are specialized wheeled chassis equipment that utilize the difference in linear speed between the wheels on opposite sides to achieve vehicle steering. Their features include compact overall dimensions, the ability to turn on the spot, and the capability to quickly swap or attach various attachments on-site. They are suitable for confined workspaces, uneven terrain, and situations requiring frequent changes in task requirements.

Application Areas

Construction: Capable of transporting construction materials such as sand and cement, performing small-scale foundation excavation, trench digging, and construction waste cleanup.

Agricultural Production: Suitable for transporting feed and fertilizer, stacking hay, leveling farmland, and clearing manure and debris from livestock farms.

Landscaping: Capable of transplanting greenery, digging tree pits, leveling land, clearing dead branches and fallen leaves, as well as transporting stones and landscape features.

Municipal Engineering: In urban road maintenance, it can be used for material transport and paving, road compaction, and also participates in trench excavation and backfilling during underground pipeline construction.

Angle of departure

25°

Max.dump heigh

1610mm

Min.ground clearance

128mm

Max.lift height of boom

2155mm

Total length (No bucket)

2278mm

Max lift height of bucket

2719mm

Track length on the ground

1065mm

Total width(No bucket)

1035mm

Bucket width

1140mm

Loading weight

475kg

Machine weight

1780kg

Track width

200mm

Fuel tank capacity

33L

Travel pump flow

61.6L/min

Engine

KUBOTA D1105/PERKINS 403J-11

Rotating speed

3000rpm

Main pump

2

Max dump angle

45°

Max.dump diatance

605mm

Height of Foot pedal to ground

228mm

Total height

1670mm

Total length (with bucket)

2835mm

Max.rotary angle of bucket

81°

Turning radius(with bucket)

1528mm

Trackbase

835mm

Bucket capacity

0.14m³

Tipping ability

1100kg

Traveling speed

10km/h

Hydraulic system pressur

21Mpa

Hydraulic oil tank capacit

30L

Working pump flow

47.6L/min

Rated power

18.2KW/18.4KW(25HP)

Noise

≤93Db

Valve

4

Accessories pump

1
